Cold Box 23.30 ltr external surface material is made of LLDPE
Cold Box 23.30 ltr internal lining material is made of LLDPE
Cold Box 23.30 ltr is also known as Large Cold Box, Long Range
WHO Reference PQS Number : E004/010
The Vaccine Storage Capacity is 23.30 Litres
The fully loaded Weight is 47 Kgs.
The Empty Weight with empty icepacks is 21.80 Kgs.
The Insulation Material is made of CFC free Polyurethane
The thickness of Insulation is 100 mm
The External Dimensions are (L x W x H) 77 x 61.5 x 51.5 cms
The Internal dimensions are (L x W x H) 52 x 37 x 28.2 cms
The Vaccine Storage Dimensions are 45 x 30 x 17.5 cms
The storage box and the Lid are Hinged & Removable
Total Number of Ice packs required are 44 x 0.4 Litre which are supplied with the unit
Ice-packs type : WHO PQS No : E005/008
The Cold Life Requirement as per WHO at 43 deg C ± 1 deg C without opening should be Minimum 140 Hours which satisfies this model.
We are Manufacturer, Exporters and Suppliers of Cold Box 23.3 ltr at wholesale competitive prices from India.
